OSMAC KR-V2000 TURRET VERTICAL MILLING MACHINE
$6,800.00 AUD
Approx. 1250 × 250 mm T-slotted table
Variable spindle speeds: 50–4200 RPM
High and low spindle-speed ranges
Longitudinal table power feed
Swivelling turret and adjustable milling head
Quill feed and fine-feed controls
Coolant tray
3-phase electrical operation
A versatile conventional milling machine with a substantial cast-iron construction.
Manufacturer/brand OSMAC
Model KR-V2000 — to confirm
Country of manufacture Taiwan
Machine number 1413
Table size Approx. 1250 × 250 mm
Longitudinal travel (X) Approx. 800 mm
Cross travel (Y) Approx. 400 mm
Vertical travel (Z) Approx. 406 mm
Quill travel Approx. 125–127 mm
Spindle speeds 50–800 / 150–4200 rpm
Spindle taper R8
Spindle motor Approx. 3 HP / 2.2 kW
Electrical supply Likely 415 V, 3 phase
Machine weight Approx. 1200–1500 kg
Equipment Variable-speed head, longitudinal power feed, coolant tray
Specs not guaranteed, if it is important ask us to check.
Approx. 1250 × 250 mm T-slotted table
Variable spindle speeds: 50–4200 RPM
High and low spindle-speed ranges
Longitudinal table power feed
Swivelling turret and adjustable milling head
Quill feed and fine-feed controls
Coolant tray
3-phase electrical operation
A versatile conventional milling machine with a substantial cast-iron construction.
Metric
| Weight | 1200–1500 |
Manufacturer/brand OSMAC
Model KR-V2000 — to confirm
Country of manufacture Taiwan
Machine number 1413
Table size Approx. 1250 × 250 mm
Longitudinal travel (X) Approx. 800 mm
Cross travel (Y) Approx. 400 mm
Vertical travel (Z) Approx. 406 mm
Quill travel Approx. 125–127 mm
Spindle speeds 50–800 / 150–4200 rpm
Spindle taper R8
Spindle motor Approx. 3 HP / 2.2 kW
Electrical supply Likely 415 V, 3 phase
Machine weight Approx. 1200–1500 kg
Equipment Variable-speed head, longitudinal power feed, coolant tray
Specs not guaranteed, if it is important ask us to check.
